Description

DC Solar submersible pump designed to create aeration for your dam
Diameter of flume: 4-5 m diameter – height 1.5 meters at full speed
Maximum flow rate: 27,000 litres per hour Maximum head 5 metres
Motor size:  750 Watt 72 volt three phase DC motor
Power supply: DC 72 Volts to run motor at full speed, lower volts will make motor run slower
Pump unit: Open impeller submersible unit, fully sealed Max revs 4000 rpm
Pump material: Stainless steel shaft, mech seal, rubber cable
Float assembly: Buoyant enough to hold pump upright.
Not bouyany enough for people, birds, animals or any other objects
There are tied down points on the float assembly for wire ropes back to dry land or an anchor used to position in middle of dam
Aerator will move around on the water surface due to wind if not anchored
No battery back up
Does not include solar panels (arrays), no array frame or installation
Must be installed by Qualified Electrician
Please contact us on mobile 0477 377 231
