Description

Applications
DC Solar swimming pool pumps are fitted with a permanent magnet DC motor which is designed for 24 hour continuous use. Swimming pool pumps deliver water economically, efficiently and reliably.

Characteristic
1. Permanent magnet,brushless motor,saving energy and offering maximum efficiency.
2. NSK bearing with alloy mechanical seal,offering the longer working life.
3. MPPT function offers higher utilization rate of solar energy.
4. Water proof and leak proof based on double water seal.
5. Controller maximum’s operating temperature:60℃
6. Featured functions:Soft start protection,High/Low voltage protection,

Over current/load protection.

Working conditions

Pump performance 15,000 lph @ 10 meters
Solar panel DC 72V, 900 watt
Water temperature:≤35℃, PH value 6.5 ~ 8.0
Suction lift up to 2 m.

4 x 275 watt Solar Panels

Polycrystalline Module Panel
CELL – Hyperion Nano Structure Rebuilding (NSR) Technology
CUT – Latest diamond cell cutting technology
COLOUR – Consistent dark blue cell colouration
CONSISTENSY – Hyperion manufactured in Phono Solar’s own 2.5GW cell facility

Dimensions – 1640mm length, 992mm width, 35mm height
18kg weight per panel
3.2mm toughened glass
Anodized aluminium alloy frame
4mm2 (IEC), 3 meters of cable
