Raindrop 2.2kW 3.0HP Single Phase 4″ Bore Pump Motor

Raindrop 2.2kW 3.0HP Single Phase 4″ Bore Pump Motor

$680.00

In stock

$680.00

2.2kW 3.0hp Single phase submersible bore motor
4” 240 Voltage 50hz water filled FLC 15.8 amps
NEMA standard 4 bolts and spline shaft
Stainless Steel AISI304 grade
Manufacturer’s warranty:  2 years
Will fit all major brands of submersible pump ends

SKU: RD2.2240M

Description

4″ water lubricated submersible motor

4″ RAINDROP submersible bore motor
Splined coupling dimensions as per NEMA standard

Motor details:  2.2kW 240Volt single phase 50hz
Motor starting: CSCR (capacitor start capacitor run) Panel required
Motor existing cable: 3 Wire + Earth
Degree of protection : IP68
Max water temperature : 35° C
Start per hour : 30 time (Max.)
Allowable voltage variation : 220V-240V +6% – 10%
Motor shaft of AISI304 Stainless Steel
Stator shell of AISI304 Stainless Steel
Max depth immersion : 200 meters
Mounting : vertical
Motor Cable length : 3 meters (3 Core+E)
Coolant : Clear Water

Manufacturer’s warranty:  2 years

Additional information

Weight 15 kg
Dimensions 60 × 10 × 10 cm

Raindrop 4" motor data
