Davey VM32-8/3 15kW Vertical Multistage Pump Replaces CR30-80, SV3208F150T, DPVF30-80

Davey VM32-8/3 15kW Vertical Multistage Pump Replaces CR30-80, SV3208F150T, DPVF30-80

In stock

Vertical multistage centrifugal pump which is used for water supply and irrigation applications

Due to Davey’s Internet Policy this product cannot be purchased online, please contact us in store for sizing and installation advice

Pump performance:  300 lpm @ 1400 kPa
Pump performance:  480 lpm @  1140 kPa
Pump performance:  600 lpm @  900 kPa

AS4020 approved for use in drinking water
Power supply:   15.0kW 415V three phase 50hz FLC  28A
Manufacturer’s warranty:  2 years

SKU: VM32-8/3

Description

Vertical multistage centrifugal pump which is used for municipal and building water supply, wash down and irrigation applications

Pump performance:  Shut off head  1520 kPa  no flow – maximum pressure
Pump performance:  300 lpm @ 1400 kPa
Pump performance:  480 lpm @  1140 kPa

Pump performance:  600 lpm @  900 kPa

AS4020 approved for use in drinking water

Material of construction:  SS/SS/SS
Power supply:   15.0kW 415V three phase 50hz FLC 28A
Impeller material: AISI304 stainless steel
Suction connection:  DIN65 Flanged
Discharge connection:  DIN65 Flanged
Starting method:  VSD or soft starter
Maximum temperature:  90 deg C
Can be used to replace other brands of multistage pump units

Manufacturer’s warranty:  2 years

Additional information

Weight210 kg
Dimensions180 × 50 × 50 cm
Brand

Davey

VM32 curve only

Download

VM32 dimensions

Download

VM Dimension table

Download
