Davey VM10-14/3 5.5kW Vertical Multistage Pump – Replaces CR8-140 SV8-14 DPVF8-140

Davey VM10-14/3 5.5kW Vertical Multistage Pump – Replaces CR8-140 SV8-14 DPVF8-140

In stock

Vertical multistage centrifugal pump which is used for water supply and irrigation applications

Due to Davey’s Internet Policy this product cannot be purchased online, please contact us in store for sizing and installation advice

Pump performance:  90 lpm @ 1430 kPa
Pump performance:  144 lpm @ 1250 kPa
Pump performance:  192 lpm @ 1100 kPa

AS4020 approved for use in drinking water
Power supply:   5.5kW 415V three phase 50hz FLC  12A
Manufacturer’s warranty:  2 years

SKU: VM10-14/3

Description

Vertical multistage centrifugal pump which is used for municipal and building water supply, wash down and irrigation applications

Pump performance:  Shut off head  1520 kPa  no flow – maximum pressure
Pump performance:  90 lpm @ 1430 kPa
Pump performance:  144 lpm @ 1250 kPa
Pump performance:  192 lpm @ 1100 kPa


AS4020 approved for use in drinking water

Material of construction:  SS/SS/SS
Power supply:   5.5kW 415V three phase 50hz FLC 12A
Impeller material: AISI304 stainless steel
Suction connection:  DIN40 Flanged
Discharge connection:  DIN40 Flanged
Starting method:  DOL, VSD or soft starter
Maximum temperature:  90 deg C
Can be used to replace other brands of multistage pump units

Manufacturer’s warranty:  2 years

Additional information

Weight90 kg
Dimensions120 × 40 × 40 cm
Brand

Davey

VM 10 curve

Download

VM Dimension Table

Download

VM10 pump dimension

Download
