ASM DT38 Three Phase Trade Waste Diaphragm Pump – 0.75kW 415volt IP66 Motor – DT38-EXD Hazardous – DT38-MINING
$3,168.00 – $5,478.00
Applications: transfer, dewatering, oil skimming, oil/water separation, waste treatment , spill clean up, bilge pumping
Connection ports: 40mm FBSP
Pump Performance : 60 litres per minute
Max suction lift: 6 metres
Max discharge head: 6 metres
Max solid size: 25 mm Sphere
Motor: DT38 0.75kw 415v three phase IP55 FLC 1.8 amps
Motor: DS38-EXD three phase for hazardous areas
Manufacturer’s warranty: 2 years
- Description
- Additional information
- Downloads
Description
Applications: transfer, dewatering, oil skimming, oil/water separation, waste treatment , spill clean up, bilge pumping
Connection ports: 40mm FBSP
Pump Performance : 60 litres per minute
Max suction lift: 6 metres
Max discharge head: 6 metres
Max solid size: 25 mm sphere
Casting: Aluminium (Options: Cast Iron, Bronze, Stainless steels)
Diaphragm : Neoprene (Options: Nitrile, EPDM, viton, teflon interface)
Valve: Neoprene flap with stainless steel seats (Options: Nitrile, EPDM, viton, polyurethane)
Motor: DT version 0.75kw 415v three phase IP55 FLC 1.8amps
Motor: DT38-EXD three phase for hazardous areas
Motor options: Single phase, Engine driven, 12V, 24V, air and hydraulic motors
Manufacturer’s warranty: 2 years
Additional information
| Weight | 54 kg |
|---|---|
| Dimensions | 55 × 40 × 66 cm |
| Brand | ASM Pumps |
| Size | DT38 0.75kW 400/3/50 diaphragm pump, DT38-EXD 0.75kW 400/3/50 hazardous diaphragm pump, DT38-MINING 0.75kW 400/3/50 diaphragm pump |
