A65-150 Self Priming Centrifugal Pump With Open Impeller – Calpeda – Bronze Version B-A65-150 – Three Phase 50hz
$2,574.00 – $6,200.00
Calpeda Self Priming Electric for many applications
For clean or slightly dirty water with solids up to 15 mm grain size for A65
Nominal pump performance
A65-150C duty: 600 lpm @ 10 metres
A65-150B duty: 600 lpm @ 15 metres
A65-150A duty: 600 lpm @ 23 metres
Suction lift up to 6 metres
Motor details:
2.2kW 2pole 400Vac IP54 FLC 5.3 amps
3.0kW 2pole 400Vac IP54 FLC 6.6 amps
4.0kW 2pole 400Vac IP54 FLC 9.6 amps
Manufacturer’s Warranty: 2 years Made in Italy
- Description
- Additional information
- Downloads
Description
Construction
Close-coupled centrifugal pumps with open impeller.
The built-in backflow preventer avoids reverse siphoning when the pump is stopped and assures automatic re-priming at the next start.
The pump re-primes itself even if partially filled with liquid and with completely empty suction pipe.
A: version with pump casing and lanter bracket in cast iron.
B-A: version with pump casing and lanter bracket in bronze (the pumps are supplied fully painted)
Suction lift up to 6 metres
Motor details: 2.2kW 2pole 400Vac IP54 FLC 5.3 amps
Motor details: 3.0kW 2pole 400Vac IP54 FLC 6.6 amps
Motor details: 4.0kW 2pole 400Vac IP54 FLC 9.6 amps
Suction inlet: 65mm Female BSP
Discharge outlet: 65mm Female BSP
Applications
For clean or slightly dirty water, also with solids up to 15 mm grain size for A 65
For draining a basin or a sump
For irrigation. For civil and industrial applications
Manufacturer’s Warranty: 2 years Made in Italy
Additional information
| Weight | N/A |
|---|---|
| Dimensions | N/A |
| Size | A65-150A three phase 4kW pump unit, A65-150B three phase 3kW pump unit, A65-150C three phase 2.2kW pump unit, B-A65-150A three phase 4kW pump unit, B-A65-150B three phase 3kW pump unit, B-A65-150C three phase 2.2kW pump unit |
