65×40-250 MGB14A-F & MGB14J-F 30HP 22kW Southern Cross Starline Motor Pump

65×40-250 MGB14A-F & MGB14J-F 30HP 22kW Southern Cross Starline Motor Pump

$5,415.00$6,085.00

In stock

$5,415.00$6,085.00

Reviews Summary by AI:

Pentair Southern Cross end suction centrifugal pumps

Flow rate:  10 lps @ 103 meters  (7,900 gph @ 1030 kPA)
Flow rate:  12 lps @ 96 meters  (9,500 gph @ 96 kPA)  End of curve

Motor specifications:  22 kW 415V three phase FLC 38 amps 2900 rpm
Material of Construction:  CI/CI/SS and CI/SS/SS
Pricing for complete pump and galv base

Manufacturer’s warranty:  2 years

SKU: MGD16A-F-1
Clear

Description

Pentair Southern Cross end suction centrifugal pumps are high quality pump made to international standards and performance.
Used in water transfer, water supply, irrigation and building/factory water supply applications

Flow rate:  8 lps @ 108 meters  (6,300 gph @ 1080 kPA)
Flow rate:  10 lps @ 103 meters  (7,900 gph @ 1030 kPA)
Flow rate:  12 lps @ 96 meters  (9,500 gph @ 96 kPA)  End of curve

Motor specifications:  22 kW 415Vac three phase FLC 38 amps IP55 2900rpm
Starting method:  Soft starter, Variable Speed Drive or Start delta starting
Material of Construction:  CI/CI/SS and CI/SS/SS
Temperature range:  0 deg C – 70 deg C
Galvanised pressed steel or fabricated base is not included in pricing however can be supplied as an option
Pricing for complete pump and galv base

Manufacturer’s warranty:  2 years

Additional information

Weight320 kg
Dimensions120 × 60 × 80 cm
Size

65×40-250 278mm CI impeller 22kW 400/3/50 on base, 65×40-250 278mm SS impeller 22kW 400/3/50 on base

Motor Electrical Data

Download

Dimensions Starline 2950rpm

Download

ISO flange dimensions

Download

65x40-250 22kW curve

Download
