125×100-250 Southern Cross ISO Sovereign Bare Shaft End Suction Pump – PSGF3A and PSGF3J – Cast Iron and Stainless Steel Models

125×100-250 Southern Cross ISO Sovereign Bare Shaft End Suction Pump – PSGF3A and PSGF3J – Cast Iron and Stainless Steel Models

$2,940.00$3,480.00

In stock

$2,940.00$3,480.00

Clear
View cart

Pump performance:  Variable performance

Speed/flow rate/head     1450 rpm / 12 meters / 11 kW
Speed/flow rate/head    3000 rpm/ 66 meters/75 kW
Southern Cross prices will increase between 10% – 15% Early 2023
Material of construction:  CI/CI/SS and CI/SS/SS
Pump connections:  Inlet 125mm flanged Outlet 100mm flanged

Manufacturer’s warranty:  2 years

SKU: PSGF3A

Description

125 x 100-250 Southern Cross Bare Shaft End Suction Pump. Application include water transfer, air conditioning transfer transfer, Diesel driven irrigation pumps, dust suppression and fire protection

Pump performance:  Variable performance
Speed/flow rate/head     1450 rpm / 12 meters / 11 kW
Speed/flow rate/head    1800 rpm / 15 meters / 15 kW
Speed/flow rate/head    2200 rpm/ 34 meters/30 kW
Speed/flow rate/head    2600 rpm/ 47 meters/45 kW
Speed/flow rate/head    3000 rpm/ 66 meters/75 kW

Material of construction:  CI/CI/SS and CI/SS/SS
CI/CI/SS :  casing/impeller/shaft

Pump connections:  Inlet 125 mm E flanged Outlet 100 mm E flanged

Mode of prime mover: Electric motor, diesel engine or pneumatic controlled

Manufacturer’s warranty:  2 years

Additional information

Weight140 kg
Dimensions80 × 60 × 60 cm
Brand

125×100-250 CI/CI/SS bare shaft, 125×100-250 CI/SS/SS bare shaft

SC ISO SOVEREIGN TECHNICAL DATA SHEET 50Hz

Download

125x100-250 curves

Download

ISO dimensions

Download

ISO flange dimensions

Download

ISO shaft dimensions

Download
