200×150-400 Southern Cross 75kW Long Coupled Pump Unit – PUJH59A and PUJH59J

200×150-400 Southern Cross 75kW Long Coupled Pump Unit – PUJH59A and PUJH59J

$15,636.36$17,654.55

In stock

$15,636.36$17,654.55

Clear
View cart

Application include water transfer, Fire protection and air conditioning transfer for cooling towers

Pump performance:    130 lps @ 400 kPA
Southern Cross prices will increase between 10% – 15% 1st December 2022

Material of construction:  CI/CI/SS and CI/SS/SS
Connections:  Suction E 200 mm Discharge E 150 mm
Electric motor 75.0kW FLC 127A 1485 rpm 4 pole TEFC

Manufacturer’s warranty:  2 years

SKU: PUJH59A

Description

200 x 150-400 Long Coupled Pump on galvanised base
Application include water transfer and air conditioning transfer for cooling towers

Pump performance:  Shut off head (zero flow) @ 58 metres
Pump performance:  50 lps @ 57 metres
Pump performance:  100 lps @ 50 metres
Pump performance:  150 lps @ 34 metres   Check NPSH(r)

Material of construction:  CI/CI/SS and CI/SS/SS
Impeller diameter: 408 mm 73% efficient
Suction limitations: check NPSH(r) on all duties
Pump Flanged connections:  Suction Table E 200 mm Discharge Table E 150 mm
Electric motor 75.0kW FLC 127A 1485 rpm 4 pole TEFC IP55 Foot mounted
Method of starting: VFD or VSD, soft starter, auto transformer or star delta

Manufacturer’s warranty:  2 years

Additional information

Weight480 kg
Dimensions180 × 60 × 60 cm
Size

200×150-500 CI/CI/SS 75kW 4pole long coupled on base, 200×150-500 CI/CI/SS 75kW 4pole long coupled w/- spacer on base, 200×150-500 CI/SS/SS 75kW 4pole long coupled on base, 200×150-500 CI/SS/SS 75kW 4pole long coupled w/- spacer on base

200x150-400 pump curve

Download

Motor Electrical Data

Download

Dimension of Pump Set

Download
