VASCO 409 4.0kW VSD Three Phase Motor Mount VFD For Pumps

VASCO 409 4.0kW VSD Three Phase Motor Mount VFD For Pumps


In stock


View cart

VASCO409 4kW VSD Variable Speed Drive
400Vac three phase 50/60hz FLC 9 amps
Motor mount version
Constant pressure control
Manufacturer’s warranty:  2 years  Made in Italy



The VASCO range of variable speed drives are cost-effective, fully featured motor mounted units which can be retrofitted to many types of pump.

Pump controlled by VFD’s:  Multistage, end suction pumps, submersible bore pumps and most centrifugal pumps

Application designs:  Constant Pressure Potable water, building water supply, Water for filtration and RO plants, commercial watering, irrigation and water transfer

Power supply:          360-440 Volt three phase 50/60hz 4.0 kW FLC 9.0 Amps
Motor Protection:   Over and under Voltage , Overload adjustable, Adjustable max and min frequency, phase failure
Pump protection:    Dry run protection, High and low pressure alarm,
Alarm response:      Audible alarm, Shut down and auto re-start
Mounting:                 Wall mounting and motor mounting options
Cascade number:    up to four (4) units can be wired together for multi pump system
Control options:      Pressure control, level control, temperature control
Transducer:              4-20mA 0-10v many options

Programming:  Contact us for information on programming and fault analyses

Manufacturer’s warranty:  12 months  Made in Italy

Additional information

Weight6.0 kg
Dimensions20 × 20 × 30 cm


Vasco manual
