Pump Three Phase Soft Starter Control Panel – FPC-15905-S Pressure Switch / Float Switch Up To 90kW

Pump Three Phase Soft Starter Control Panel – FPC-15905-S Pressure Switch / Float Switch Up To 90kW

$2,260.00$3,900.00

In stock

$2,260.00$3,900.00

Reviews Summary by AI:

Pump control panel to start and stop a pump.
Manual/off/Auto selector switch gives the ability to start and stop your pump manually or via a pressure switch or float switch

Mains isolation switch for shutting down power supply
Thermal overload to protect your pump and cable
Metal enclosure sizing on request

Manufacturer’s warranty: 12 months

SKU: FPC-15905-S
Clear

Description

Soft Starter Pump control panel to start and stop a pump.
Manual/off/Auto selector switch gives the ability to start and stop your pump manually or via a pressure switch or float switch

Control & interface:
Selector switch for auto/off/manual control of pump
Soft starter with user adjustable soft start and soft stop (Soft Start version)

Inputs:
Three phase (400/3/50) power supply
2 x 24Vac digital inputs for cut off and working level float, pressure or other switches

Outputs:
Pump supply output

Enclosure:
Powder coated mild steel enclosure with removable gland plate
IP56 rated with inner door (Soft Start version)
Enclosure sizes will increase for size of Soft Starter – contact for sizing

Protection:
Pad-lockable mains power isolator switch
Circuit breaker protected low voltage control and input circuitry
Contactor and thermal overload protection of pump
Din rail mounted terminal connections

Additional information

WeightN/A
DimensionsN/A
Size

S11 Soft Starter Panel 11.0kW 400/3/50, S15 Soft Starter Panel 15.0kW 400/3/50, S22 Soft Starter Panel 22.0kW 400/3/50, S30 Soft Starter Panel 30.0kW 400/3/50, S37 Soft Starter Panel 37.0kW 400/3/50, S4.0 Soft Starter Panel 4.0kW 400/3/50, S45 Soft Starter Panel 45.0kW 400/3/50, S5.5 Soft Starter Panel 5.5kW 400/3/50, S55 Soft Starter Panel 55.0kW 400/3/50, S7.5 Soft Starter Panel 7.5kW 400/3/50, S75 Soft Starter Panel 75.0kW 400/3/50, S90 Soft Starter Panel 90.0kW 400/3/50

FPC-15905 data

Download
