Description

STAR PRO Close Coupled – Pump and Motor with galvanised base plate
Designed for efficient and reliable water transfer in agriculture, industry, commerical pools and mining
MUGC14J-F  80×50-250 SS/SS/SS 22kW 400/3/50 2pole motor pump unit
MUGC15J-F  80×50-250 SS/SS/SS 30kW 400/3/50 2pole motor pump unit
MUGC16J-F  80×50-250 SS/SS/SS 37kW 400/3/50 2pole motor pump unit
MUGC17J-F  80×50-250 SS/SS/SS 45kW 400/3/50 2pole motor pump unit
MUGC18J-F  80×50-250 SS/SS/SS 55kW 400/3/50 2pole motor pump unit
Features:
Superior hydraulic design and manufacturing methods produce significantly higher efficiencies for lower running costs and reduced maintenance.
Australian designed and manufactured
Flow rate: call us to discuss
Australian wide service and backup
ISO 9001 Quality assured
Suction: 80mm Table E flanged
Discharge: 50mm Table E flanged
Standard Features:
TEFC 400/3/50 2pole IP55 motor
Maximum Working Pressure rated to 1600kPa (16bar)
Casing: 316 investment cast stainlesss teel
Impeller: 316 investment cast stainless steel
Shaft:  316 stainless steel
Mechanical seal:  Silcon/Silcon/Viton
All wetted areas are 316 stainless steel
Rigid cast iron bell housing connects motor and pump housing
Single mechanical seal

Manufacturer’s warranty:  2 years
