4 inch 0.7kW 1.0hp Three Phase Submersible Bore Motor Raindrop – Suits Grundfos LOWARA Franklin Pump Ends – $495.00 Incl GST – RDSM407
$495.00
0.7kw 1.0hp three phase 415volt 50hz submersible motor
NEMA standard
Stainless Steel AISI304 grade
Will fit all major brands of submersible pump ends
Manufacturer’s warranty: 2 years
- Description
- Additional information
- Downloads
Description
4″ 0.75kW 1.0hp Water Lubricated Submersible Motor
4″ Raindrop Water Lubricated Motors are rewindable
Coupling dimensions as per NEMA standard
Degree of protection : IP68
Max water temperature : 35° C
Start per hour : 30 time (Max.)
Allowable voltage variation +6% – 10%
Motor shaft of Stainless Steel
Stator shell of Stainless Steel
Max depth immersion : 200 metres
Mounting : vertical / horizontal
Upper Bracket Steel Cast/ Lower bracket with SS Cladding
Motor Cable length : 3 metres (4C)
Coolant : Clear Water
Motors with other Voltage and frequency ratings are also available on specific demand.
Additional information
| Weight | 12 kg |
|---|---|
| Dimensions | 40 × 12 × 12 cm |
| Brand | Raindrop |
