350×300-315 PTHL5J Southern Cross ISO Bare Shaft End Suction Pump – CI/SS/SS Construction
$51,640.00
350×300-315 Southern Cross Bare Shaft End Suction Pump
Material of construction: CI/SS/SS
Casing: High grade Cast iron housing AS1830/T260
Impeller: 316 investment cast stainless steel
Shaft: Heavy duty431 stainless steel
Pump connections: Inlet 350mm flanged Outlet 300mm flanged
Manufacturer’s warranty: 2 years
- Description
- Additional information
- Downloads
Description
350×300-315 Southern Cross Bare Shaft End Suction Pump.
Ideal for efficient and reliable general purpose water transfer in industry and irrigation
Material of construction: CI/SS/SS
Casing: High grade Cast iron housing AS1830/T260
Impeller: 316 investment cast stainless steel
Shaft: Heavy duty431 stainless steel
Mechanical seal: SiC/SiC/Viton
Bearings: Heavy duty deep grooved ball bearings
Pump connections: Inlet 350 mm E flanged Outlet 300 mm E flanged
Mode of prime mover: Electric motor, diesel engine or pneumatic controlled
Manufacturer’s warranty: 2 years
Additional information
| Weight | 140 kg |
|---|---|
| Dimensions | 80 × 60 × 60 cm |
| Brand | PTHL5J 350×300-315 bare shaft pump |
