Description

HS-series is a submersible single-phase portable drainage pump.
Though it is a single-phase unit, the pump has the durability equivalent to three-phase drainage pumps, since the wear parts are made of abrasion-resistant materials.
The side discharge, spiral design allows smoother passage of the sucked solid matters.
The shaft-mounted agitator prevents “Air Lock” that tends to take place on vortex or semi-vortex pumps.

Pump performance:  30 lpm @ 16 metres
Pump performance:  60 lpm @ 15 metres
Pump performance:  120 lpm @ 12 metres
Pump performance:  200 lpm @ 6.5 metres

• Spiral Design and anti-wicking cable entry
• Thermal motor protection
• Dual Inside Mechanical Seal
• Oil Lifter [Patented]
• 10 metre motor lead with Australian 3 pin plug
• Rubber / Resin-made Stand
• Agitator (HS/HSZ/HSD)

Electrical data: 240/1/50 FLC 4.8A Starting current 14.6A
Weight:  19kg

Manufacturer’s warranty:  2 years Made in Japan
