Wet End 90lpm or 1200gph 6GS05 6GS07 6GS11 6GS15 6GS22 6GS30 6GS40 6GS55- Lowara Pump End Only

Wet End 90lpm or 1200gph 6GS05 6GS07 6GS11 6GS15 6GS22 6GS30 6GS40 6GS55- Lowara Pump End Only

$610.00$1,740.00

In stock

$610.00$1,740.00

Clear
View cart

Lowara 6GS series of Submersible Bore Pump End
Lowara is a floating stack pump end which allows for small amounts of sand to be pumped
Pump performance: 6GS05   90lpm @ 20 metres
Pump performance: 6GS07   90lpm @ 30 metres
Pump performance: 6GS11   90lpm @ 42 metres
Pump performance: 6GS15   90lpm @ 60 metres
Pump performance: 6GS22   90lpm @ 92 metres
Pump performance: 6GS30   90lpm @ 130 metres
Pump performance: 6GS40   90lpm @ 150 metres
Pump performance: 6GS55R   90lpm @ 200 metres
Pump performance: 6GS55   90lpm @ 240 metres



Manufacturer’s warranty:  2 years

SKU: N/A

Description

Lowara 6GS Submersible Pump End is designed to operate between 50lpm to 120lpm

Pump performance: 6GS05   90lpm @ 20 metres
Pump performance: 6GS07   90lpm @ 30 metres
Pump performance: 6GS11   90lpm @ 42 metres
Pump performance: 6GS15   90lpm @ 60 metres
Pump performance: 6GS22   90lpm @ 92 metres
Pump performance: 6GS30   90lpm @ 130 metres
Pump performance: 6GS40   90lpm @ 150 metres
Pump performance: 6GS55R   90lpm @ 200 metres
Pump performance: 6GS55   90lpm @ 240 metres

For water and potable water supply from boreholes
4” Submersible pump for vertical or horizontal installation
32mm Female BSP outlet

Easy installation through integrated non-return valve
Can be installed with any NEMA standard 4inch submersible bore motor

Long service life thanks to corrosion-resistant AISI304 stainless steel

Manufacturer’s warranty:  2 years

Additional information

Weight26 kg
Dimensions140 × 12 × 12 cm
Size

6GS05 pump end only with 32mm female outlet, 6GS07 pump end only with 32mm female outlet, 6GS11 pump end only with 32mm female outlet, 6GS15 pump end only with 32mm female outlet, 6GS22 pump end only with 32mm female outlet, 6GS30 pump end only with 32mm female outlet, 6GS40 pump end only with 32mm female outlet, 6GS55 pump end only with 32mm female outlet, 6GS55R pump end only with 32mm female outlet

6GS pump curve and technical data

Download

6GS dimensional drawings

Download
