GB4KQ-A/ST HYD GMP Water Truck Self Priming Hydraulic Driven 4inch Pump – Semi Trash Pump 7kW Code ASM7 & 12.5kW Code ASD8
$6,754.00 – $6,908.00
4″ Cast iron pump coupled to hydraulic driven motor to suit water truck
Self Priming to 6 meters
ASM7 … GB4KQ-A/ST HYD22 … 22cm3 150bar 7kW
ASD8 … GB4KQ-A/ST HYD … 34cm3 100bar 12.5kW
Pump performance: 600 lpm @ 120 kPA
Pump performance: 100 lpm @ 80 kPA
Pump connections: Suction and discharge 100mm FBSP
Impeller: Open non clog style impeller
Italian made hydraulic motor
Manufacturer’s warranty: 3 years
- Description
- Additional information
- Downloads
Description
4″ Cast iron pump coupled to hydraulic driven motor to suit water truck
Self Priming to 6 meters
ASM7 … GB4KQ-A/ST HYD22 … 22cm3 150bar 7kW
ASD8 … GB4KQ-A/ST HYD … 34cm3 100bar 12.5kW
Pump performance: 600 lpm @ 120 kPA flooded suction
Pump performance: 1000 lpm @ 80 kPA flooded suction
Pump performance: 1500 lpm @ 40 kPA flooded suction
Pump connections: Suction and discharge 100mm FBSP
Impeller: Open non clog style impeller
Front mounted clean out port
Mechanical seal: Silicon carbide seal faces
Italian made hydraulic motor
Manufacturer’s warranty: 3 years
Additional information
| Weight | 90 kg |
|---|---|
| Dimensions | 60 × 40 × 50 cm |
| Size | ASD8 12.5kW Hydraulic driven 100mm Semi Thrash pump, ASM7 7kW Hydraulic driven 100mm Semi Thrash pump |
