Solar Swimming Pool Pump & Controller SSP550B – 500Vdc Power Supply
Model: SPP500B
Solar Pool Pump and controller
Pump performance: 10,000 lph @ 10 metres
48 voltage, 550 watt
2″x 2″ outlet
MC4 connectors and 3meter cables
- Description
- Additional information
- Downloads
Description
Applications
DC Solar swimming pool pumps are fitted with a permanent magnet DC motors which are designed for 24 hour continuous use. Swimming pool pumps systems deliver water economically, cleanly and reliably.
Characteristic
1. Permanent magnet, brush less motor,saving energy and offering maximum efficiency.
2. NSK bearing with alloy mechanical seal,offering the longer working life.
3. MPPT function offers higher utilization rate of solar energy.
4. Water proof and leak proof based on double water seal.
5. Controller maximum’s operating temperature:60℃
6. Featured functions:Soft start protection,High/Low voltage protection,
Over current/load protection.
Working conditions
Pump performance: duty 10,000 lph @ 10 metres
DC Power supplied by solar panels
DC48 Solar pump: 48v, 550 watt
Water temperature:≤35℃, PH value 6.5 ~ 8.0
Suction lift up to 2 m.
Additional information
| Weight | 5 kg |
|---|---|
| Dimensions | 50 × 30 × 40 cm |
