MS6000 & MS6000R Grundfos 7.5kW 304 & 904L Stainless Steel 415volt Three Phase 50hz Submersible Bore Pump Motor 96024868 & 96432340
$3,960.00 – $7,920.00
MS6000 and MS6000R Grundfos three phase submersible bore motor
6”, 400 Voltage 50hz water filled
NEMA standard
Stainless Steel 304 and 904L grade
Will fit all major brands of submersible pump ends
Manufacturer’s warranty: 2 years
- Description
- Additional information
- Downloads
Description
MS6000 6″ 304 stainless steel 7.5kW water lubricated submersible motor
MS6000R 6″ 904L stainless steel 7.5kW water lubricated submersible motor
6″ Grundfos submersible bore motor
Coupling dimensions as per NEMA standard.
Degree of protection : IP68
Max water temperature : 35° C
Start per hour : 20 time (Max.)
Allowable voltage variation +6% – 10%
Motor construction: 904L stainless steel –
Max depth immersion : 200 metres
Mounting : vertical or horizontal
Motor Cable length : 3 metre (3 Core / 4 Core)
Coolant : Clear Water
Manufacturer’s warranty: 2 years
Additional information
| Weight | 34 kg |
|---|---|
| Dimensions | 90 × 12 × 12 cm |
| Brand | Raindrop |
| Size | 7.5kW MS6000 400/3/50 304ss 6inch submersible motor, 7.5kW MS6000R 400/3/50 904L ss 6inch submersible motor |
