Grundfos CRI15-9 Flanged 7.5kW Three Phase Multistage Pump Unit

Grundfos CRI15-9 Flanged 7.5kW Three Phase Multistage Pump Unit

$4,580.00

In stock

$4,580.00

Grundfos CRI15-9 is used for Potable water applications and water transfer

Flow rate:  300 lpm @ 700 kPa  (70 meters)
Flow rate:  360 lpm @ 600 kPa  (60 meters)

Motor details: 7.5 kW 400/3/50 FLC 15A IP56 E3
All wetted parts are AISI304 stainless steel as a minimum
Temperature of pumped liquid: from -10°C to 110°C
Potable water supply applications

Manufacturer’s warranty:  2 years

SKU: CRI15-9
View cart

Description

Grundfos CRI15-9 is used for Potable water applications and water transfer
Pump is approved for Australian Standard AS4020 Drinking Water Approved

Flow rate:  zero lps @ 980 kPa  (98 meters)
Flow rate:   120 lpm @ 900 kPa  (90 meters)
Flow rate:   240 lpm @ 780 kPa  (78 meters)
Flow rate:  300 lpm @ 600 kPa  (60 meters)
Flow rate:  360 lpm @ 500 kPa  (50 meters)

Motor details: 7.5 kW 400/3/50 FLC 15A IP56 E3
All wetted parts are AISI304 stainless steel as a minimum
Impellers and Diffusers: AISI304 stainless steel
Maximum operating pressure: 25 bar
Pump connections: DIN50 PN25 cast iron
Temperature of pumped liquid: from -30°C to 120°C
Water supply and booster systems

Grundfos pumps can be used in many applications including:
Potable water supply in buildings and towns
Water treatment and RO
Hot water applications
Irrigation and boiler feed applications

Manufacturer’s warranty:  2 years

Additional information

Weight80 kg
Dimensions140 × 40 × 40 cm
