Description

Grundfos CR15-7 used for water transfer, boiler feed and irrigation

Flow rate:  zero lps @ 980 kPa  (98 meters)
Flow rate:   120 lpm @ 940 kPa  (94 meters)
Flow rate:   240 lpm @ 840 kPa  (84 meters)
Flow rate:  300 lpm @ 740 kPa  (74 meters)
Flow rate:  360 lpm @ 620 kPa  (62 meters)

Motor details: 5.5 kW 400/3/50 FLC 11A IP56 E3
Cast Iron pump casings and stainless steel sleeve
Impellers and Diffusers: AISI304 stainless steel
Maximum operating pressure: 25 bar
Pump connections: DIN50 PN25 4 hole cast iron flanged
Temperature of pumped liquid: from -10°C to 100°C
Water supply and booster systems

Grundfos pumps can be used in many applications including:
Hot water applications
Irrigation and boiler feed applications

Manufacturer’s warranty:  2 years
