Description

37kW 6″ 1000 volt Submersible Motor can be installed on all wet ends with Spline Coupling.
Can be used on following pump ends: Franklin, Lowara, Southern Cross, TKL, Goulds and Grundfos

Specifications:

• Hermetically sealed stator, anti track self healing stator resin prevents motor burn out
• Removable Water Bloc™ lead connector
• Cable material according to drinking water regulations (KTW approved)
• All motors are prefilled with water and 100% tested
  Technical Specifications:

• 37.0 kW 6″ NEMA flange, Outside Diameter 138 mm
• Starts per hour: max. 10 vertical or horizontal installation
• Standard voltage: 1000 V/50Hz FLC  28 Amps
• Insulation: Class F Rated ambient temperature: 30°C ,Cooling flow: min. 0.16 m/s
• Star Delta Motor leads in 4 meter length (KTW approved)
• Types of starting Soft Starter, VSD or VFD, Auto Transformer (please call to discuss)

Please call for pricing, more information or to discuss

Manufacturer’s warranty:  1 years   Made in USA
