DAB ESYBOX MINI VSD Pressure Pump – Constant Pressure Energy Savings

DAB ESYBOX MINI VSD Pressure Pump – Constant Pressure Energy Savings


In stock


View cart

Operating range: capacity up to 80 l/min; head up to 55 m
Maximum suction depth: 8 meters
Maximum operating pressure: 7.5 bar (750 kPa) includes inlet pressure
Horizontal or vertical fixed position

Manufacturer’s warranty:  2 years  Made in Italy

SKU: 805406


E.SYBOX MINI3 is the DAB compact automatic pressurisation system for the water supply of a single dwelling. E.SYBOX MINI3 guarantees the comfort of constant pressure (Pressure Set Point adjustable from 1 up to 5.5 bar) inside the system, and energy savings thanks to the inverter technology.

Suitable for use with drinking water, in domestic systems, and in gardening applications

Pump performance:   40 lpm @ 350 kPa

AS4020 approved for use in drinking water

It consists of a high frequency self-priming multistage pump, management inverter electronics, pressure and flow sensors, adjustable high resolution LCD display with 1 litre built-in expansion vessel, and cartridge check valve.
The double suction and delivery ports allow both vertical and horizontal installation.
Thanks to its compact size and water cooled motor, installation is possible in small places with low air flow.
The E.SYWALL wall bracket allows wall installation, saving even more room.
E.SYBOX MINI3 is a self-priming pump with a capability of 8 meters.
The water cooled motor, the anti-vibration feet and the electronics, make this product totally comfortable and compact.
Fitted with safety protections including dry run and antifreeze protection.
All the parameters and the operating status can be displayed and set on the high resolution LCD display.

Manufacturer’s warranty:  2 years  Made in Italy

Additional information

Weight16 kg
Dimensions50 × 30 × 32 cm
