Grundfos CRI15-9 Part Number 96501918 – Flanged 7.5kW Three Phase Multistage Pump Unit – CR15-9 – Part Number 96501900
$5,680.00 – $5,960.00
Grundfos CRI15-9 is used for Potable water applications and water transfer
CRI15-9 material of construction: SS/SS/SS
CR15-9 material of construction: CI/SS/SS
Motor details: 7.5 kW 400/3/50 FLC 15A IP56 E3
Temperature of pumped liquid: from -10°C to 110°C
Potable water supply applications
Manufacturer’s warranty: 2 years
- Description
- Additional information
- Downloads
Description
Grundfos CRI15-9 is used for potable water applications and water transfer
Pump is approved for Australian Standard AS4020 Drinking Water Approved
CRI15-9 material of construction: SS/SS/SS
CR15-9 material of construction: CI/SS/SS
Motor details: 7.5 kW 400/3/50 FLC 15A IP56 E3
Maximum operating pressure: 16 bar
Pump connections: DIN50 PN16 cast iron round flange
Temperature of pumped liquid: from -30°C to 120°C
Water supply and booster systems
Grundfos pumps can be used in many applications including:
Potable water supply in buildings and towns
Water treatment and RO
Hot water applications
Irrigation and boiler feed applications
Manufacturer’s warranty: 2 years
Additional information
| Weight | 80 kg |
|---|---|
| Dimensions | 140 × 40 × 40 cm |
| Size | CR15-9 7.5kW multistage pump unit, CRI15-9 7.5kW multistage pump unit |
