Ebara 3D 50-160/7.5 10HP Three Phase Pump Centrifugal Motor Pump for Irrigation and Water Transfer
![](https://i0.wp.com/pumpsandpipes.net.au/wp-content/uploads/2020/03/Ebara-3D-50-160-7.5.png?resize=150%2C150&ssl=1)
Ebara 3D 50-160/7.5 10HP Three Phase Pump Centrifugal Motor Pump for Irrigation and Water Transfer
$2,550.00
$2,550.00
Reviews Summary by AI:
End suction centrifugal pump which is used for industrial and factory water transfer, wash down and irrigation pump
Pump performance: 1000 lpm @ 300 kPa
Power supply: 7.5kW 415V three phase 50hz FLC 13.9A
Manufacturer’s warranty: 2 years Made in Italy
- Description
- Additional information
- Downloads
Description
End suction centrifugal pump which is used for industrial and factory water transfer, wash down and irrigation pump
Pump performance: Shut off head 390 kPa (52 psi) no flow maximum pressure
600 lpm @ 370kPa
1000 lpm @ 300 kPa
1200 lpm @ 270 kPa
Material of construction: CI/SS/SS
Power supply: 7.5kW 415V three phase 50hz FLC 13.9A
Impeller material: AISI304 stainless steel
Impeller diameter: 200 mm
Suction connection: DIN65 Flanged
Discharge connection: DIN50 Flanged
Starting method: VSD or soft starter (DOL check local electrical supply)
Maximum temperature: 90 deg C
Manufacturer’s warranty: 2 years Made in Italy
Additional information
Weight | 65 kg |
---|---|
Dimensions | 70 × 40 × 40 cm |
Brand | Ebara |
