Butterfly Valve 6″ 150mm Lugged Lever Handle
$296.00
Applications Include Industrial liquid transfer, Water trucks and Irrigation
Ductile Iron Lugged to Suit Table E flange Standard
Lever Operation with Notch Plate
EPDM Seat & 316 Stainless Steel Splined Disc
Vacuum to 16 Bar Pressure Range
Media Temperature: -20°C to 120°C
Lugged Cast Iron Body
AISI316 Stainless disc and an EPDM Seat
Pattern: BS Table E with 8 x M16
- Description
- Additional information
- Downloads
Description
Applications Include Water Trucks, Irrigation and Other Industrial applications
Ductile Iron Lugged to Suit Table E flange Standard
Lever Operation with Notch Plate
EPDM Seat & 316 Stainless Steel Splined Disc
Vacuum to 16 Bar Pressure Range
Media Temperature: -20°C to 120°C
Watermark & Standards mark Approved
Lugged Cast Iron Body
AISI316 Stainless disc and an EPDM Seat
Pattern: BS Table D/E with 8 x M16
Additional information
| Weight | 6 kg |
|---|---|
| Dimensions | 30 × 30 × 10 cm |
